SOLE F85 Treadmill Dimensions & Assembly Guide

Key Takeaways

• The SOLE F85 treadmill features a powerful 4.0 HP motor for smooth and consistent performance; and a spacious 22" x 60" running surface to accommodate users of all sizes.
• Assembled dimensions for the SOLE F85 are 82.5"L x 38"W x 66"H, and folded dimensions are 44"L x 38"W x 71.5"H.
• Assembly is straightforward with clear instructions, but professional assembly is available for an additional fee.

At SOLE Fitness, we're proud to offer the best treadmills for your home or gym. These machines are crafted to meet the highest standards of quality and performance, ensuring they are ideal for anyone - from fitness novices to seasoned athletes. Featured Product SOLE Treadmills: Starting at $1,199.99, SOLE treadmills excel in ergonomic design, durability, and value. Equipped with advanced cushioning to minimize joint impact, powerful, quiet motors, and wide running surfaces, they suit any fitness level.

SOLE F85 Treadmill Dimensions

• Boxed Dimensions: 86"L x 39"W x 15"H
• Assembled Dimensions: 82.5"L x 38"W x 66"H
• Folded Dimensions: 44"L x 38"W x 71.5"H
• Step Up Height: 8"
• Weight Capacity: 375 lbs
• Item Weight: 294 lbs
• Boxed Weight: 324 lbs

Boxed Dimensions
When the F85 treadmill is delivered, it will come in a box measuring 86 inches long, 39 inches wide, and 15 inches high. Being aware of these dimensions allows you to plan for the delivery and make sure you have adequate space to unpack the treadmill safely.

Assembled Dimensions
When fully assembled, the SOLE F85 treadmill measures 82.5 inches in length, 38 inches in width, and 66 inches in height.

These dimensions make it a substantial piece of equipment, so ensure you have enough space in your home gym or workout area.

The large footprint of the treadmill provides stability and support, even during high-intensity workouts.

Folded Dimensions
A significant advantage of the SOLE F85 treadmill is its space-saving foldable design.

When folded using the release lever mechanism, the treadmill's dimensions are 44 inches long, 38 inches wide, and 71.5 inches high. This compact size makes it easy to store in smaller areas like a closet or a room corner when not in use.

Weight Limit
The SOLE F85 treadmill, weighing 294 lbs, is built to be a robust and stable piece of equipment. It has a weight capacity of 375 lbs, accommodating a wide range of users.

Space Requirements
Before setting up your SOLE F85 treadmill, it’s important to consider the space requirements. This treadmill is a significant piece of equipment, and you’ll need enough room to use it comfortably and safely.

Besides the treadmill’s assembled dimensions, you should also allow for additional space around the machine. Ideally, you should have at least two feet of clearance on either side and three feet behind the treadmill, just so you can move comfortably while handling it.

SOLE F85 Treadmill Assembly Guide

Preparation
Before you begin the assembly process, gather all the necessary tools and parts.

The SOLE F85 treadmill package includes all the bolts, screws, and tools you’ll need. However, having an extra set of hands to help can make the process easier and faster.

Make sure you have a clear, well-lit space to work in. Lay out all the parts and tools, and double-check the assembly manual to ensure you understand each step.

Having a clean, organized workspace will help you avoid losing any small parts and make the assembly process more efficient.

Step-by-Step SOLE F85 Assembly Instructions
Follow these steps to assemble your SOLE F85 treadmill:

1. Remove the treadmill from the carton and position it on a smooth, level floor. The rear should be at least 3 feet from any wall.
2. Attach the treadmill deck to the frame. Use the provided bolts and screws to secure the deck in place. Make sure the deck is aligned properly before tightening the bolts.
3. Install the console mast. This step involves attaching the vertical posts to the treadmill base. Ensure the mast is securely fastened and stable.
4. Connect the console cables. Carefully thread the cables through the mast and connect them to the console. Be gentle to avoid damaging the cables.
5. Attach the console to the mast. Secure the console with the provided screws, ensuring it’s firmly in place.
6. Install the handrails. Attach the handrails to the console mast and treadmill base. Make sure they are securely fastened and stable.
7. Double-check all connections and tighten any loose bolts or screws. Ensure that the treadmill is stable and all parts are securely fastened.

Accessory Installation
The SOLE F85 treadmill comes with various accessories to enhance your workout experience. Here's how to install some of the common accessories:

• Tablet Holder: Attach the tablet holder to the console using the provided screws. Ensure it is securely fastened and can hold your device without wobbling.
• Water Bottle Holder: The water bottle holder can be attached to the side of the console - make sure it’s within easy reach but does not obstruct your movement.
• Heart Rate Monitor: If your treadmill includes a heart rate monitor, follow the instructions to connect it to the console - double check the monitor is working correctly and providing accurate readings.

Common Assembly Issues
During the assembly process, you might encounter some common issues. Here are a few tips to help you troubleshoot:

• Loose Bolts: If you notice any loose bolts, double-check the alignment of the parts and tighten the bolts securely.
• Cable Connections: Ensure all cables are connected properly. If the console isn’t working, recheck the cable connections to make sure they are secure.
• Unstable Frame: If the treadmill feels unstable, check all bolts and screws to ensure they are tightened correctly. You may also need to adjust the leveling feet to stabilize the treadmill.

Final Setup
Once the assembly is complete, it’s time for the final setup. Plug in the treadmill and turn it on. Follow the on-screen instructions to set up your user profile and calibrate the treadmill.

Make sure to test the treadmill by walking and running on it at different speeds.

Check that all functions, such as incline and speed adjustments, are working correctly. If everything is functioning properly, you’re ready to start your workouts.

Check the SOLE F85 manual for specific instructions.

Additional SOLE F85 Setup Tips

Initial Calibration
Calibrating your treadmill is essential for accurate performance.

Follow the manufacturer’s instructions to calibrate the speed and incline settings to make sure that the treadmill operates correctly and provides accurate feedback during your workouts.

Maintenance Tips
Regular maintenance is essential to keep your SOLE F85 treadmill running smoothly and to extend its lifespan. Here are some important maintenance tips to follow:

• Clean the Belt: After each workout, use a damp cloth to wipe down the treadmill belt. This removes sweat, dust, and debris that can accumulate and cause wear over time.
• Lubricate the Belt: Depending on your usage, you should lubricate the treadmill belt every three to six months. Use a silicone-based lubricant as recommended by the manufacturer to reduce friction and keep the belt running smoothly.
• Inspect for Wear and Tear: Regularly check the treadmill for any signs of wear and tear. Pay close attention to the belt, motor, and rollers. If you notice any issues, address them promptly to avoid further damage.
• Check the Console: Ensure the console is functioning correctly. Check all buttons, displays, and connections to make sure everything is in working order.

Safety Precautions
Using the SOLE F85 treadmill safely is crucial to prevent accidents and injuries. Here are some key safety precautions to keep in mind:

• Use the Safety Key: Always attach the safety key to your clothing. This key will automatically stop the treadmill if you fall or move too far from the console, providing an essential safety measure.
• Start Slowly: Begin each workout at a slow speed to warm up your muscles and prevent strains, then gradually increase the speed and intensity as your body adjusts.
• Stay Hydrated: Dehydration can lead to dizziness and fatigue, increasing the risk of injury. Keep a water bottle within reach to stay hydrated during your workout.
• Maintain Proper Form: Pay attention to your posture and running form. Keep your back straight, shoulders relaxed, and arms at your sides. Proper form reduces the risk of injury and improves workout efficiency.

Frequently Asked Questions

How much space do I need for the SOLE F85 treadmill?
The SOLE F85 treadmill requires a significant amount of space due to its large dimensions. When fully assembled, the treadmill measures 82.5 inches in length, 38 inches in width, and 66 inches in height. Additionally, it is recommended to have at least two feet of clearance on either side and three feet behind the treadmill to ensure safe and comfortable use.

When folded, the treadmill's dimensions are 44 inches in length, 38 inches in width, and 71.5 inches in height.

Can I move the treadmill once it's fully assembled?
Yes, the SOLE F85 treadmill is designed to be moved even after it is fully assembled. It comes with transport wheels that make it easier to relocate the treadmill within your home.

To move the treadmill, ensure it is in the folded position, and then carefully tilt it onto the transport wheels. Push or pull the treadmill to the desired location, making sure to avoid any obstacles or uneven surfaces.

What if a part is missing or damaged during assembly?
If you find that a part is missing or damaged during the assembly process, don’t worry. At SOLE Fitness, we provide excellent customer support to help you resolve such issues. Contact our customer service team with details about the missing or damaged part, and we will assist you in getting a replacement.

• Phone: 866-780-7653
• Email: info@soletreadmills.com
• Online chat: Available on the SOLE Fitness website

Have your treadmill’s model number and purchase information ready when you contact customer support. Additionally, you can refer to the assembly manual for part numbers and descriptions, which will make it easier to communicate the issue to the support team.

How often should I perform maintenance on the treadmill?
Regular maintenance is key to keeping your SOLE F85 treadmill in optimal condition. Here are some general guidelines for how often you should perform maintenance tasks:

• Weekly: Wipe down the treadmill belt and console to remove sweat and dust. Check for any loose bolts or screws.
• Monthly: Inspect the treadmill for signs of wear and tear. Lubricate the belt if necessary.
• Quarterly: Perform a thorough inspection of the treadmill’s motor, rollers, and other moving parts. Tighten any loose bolts and screws.
• Annually: Consider having a professional technician perform a comprehensive maintenance check to ensure all components are in good working order.

Is professional assembly recommended for this treadmill?
While the SOLE F85 treadmill can be assembled by following the provided instructions, some users may prefer to opt for professional assembly.

Professional assembly services are available for an additional fee and can provide peace of mind, especially if you’re not comfortable with DIY assembly or if you want to ensure the treadmill is set up correctly. If you choose to go this route, make sure to schedule the assembly service when you purchase the treadmill.
